Galaxy White

Galaxy White | 800 x 3200 mm | Large Format Porcelain Slab | Megan Cera

E-Catalogue

Tiles Calculator

Product Name	Galaxy White
Size	800x3200 MM
Benefits	Easy to Clean, Low Maintenance, Water Proof, Aesthetic Appeal, Non-Slip, Ecological
Resistance Properties	Scratch Resistance, Chemical Resistance, UV Resistance, Heat Resistance, Fire Resistance
Applications	Backsplashes, Staircases, Bathroom Floors, Kitchen Islands, Fireplaces

Characteristics	Standard as per ISO-13006/EN14411 Group	Values	Test Method
Regulatory Properties
Deviation in Length & Width	+0.5%	+0.2%	ISO 10545-2
Deviation in Thickness	±5%	±5%	ISO 10545-2
Straightness of Sides	+0.5%	+0.2%	ISO 10545-2
Rectangularity	+0.5%	+0.2%	ISO 10545-2
Surface Flatness	+0.5%	+0.3%	ISO 10545-2
Color Difference	ΔE≤1.00	ΔE≤0.30	ISO 10545-16
Glossiness	As per Mfg.	>90%	Gloss Meter 60
Structural Properties
Water Absorption	≤0.5%	≤0.06%	ISO 10545-3
Apparent Density	As per Mfg.	>2.20 g/cc	ISO 10545-3
Massive Mechanical Properties
Modulus of Rupture	Min. 35N/mm²	Min. 40N/mm²	ISO 10545-4
Breaking Strength	Min. 1300 N	Min. 7200 N	ISO 10545-4
Impact Resistance	As per Mfg.	Min. 0.55	ISO 10545-4
Surface Mechanical Properties
Surface Abrasion Resistance	As per Mfg.	Min. class 3	ISO 10545-7
Moh’s Hardness	As per Mfg.	Min. class 4	BS EN 15771
Thermo Hygrometric Properties
Frost Resistance	As per Mfg.	Frost Proof	ISO 10545-12
Thermal Shock Resistance	Min. 10 Cycle	Min. 10 Cycle	ISO 10545-9
Moisture Expansion	Max. 0.6mm/m	Max. 0.02mm/m	ISO 10545-10
Thermal Expansion	Max. 9.0 x 10⁻⁶	Max. 6.0 x 10⁻⁶	ISO 10545-8
Chemical Properties
Chemical Resistance	As per Mfg.	No Damage	ISO 10545-13
Stain Resistance	Resistant	Resistant	ISO 10545-14
Safety Properties
Slip Resistance	As per Mfg.	N, A	DIN 51130
Fire Resistance	As per Mfg.	Fire Proof	N, A
