Onyx Green

Onyx Green | 1200 x 2800 mm | Large Format Porcelain Slab | Megan Cera

E-Catalogue

Tiles Calculator

Product Category	Large Format Porcelain Slab
Product Name	Onyx Green
Thickness	6mm / 9mm / 15mm
Body Type	Whitebody
Finish	Bookmatch Gloss
Applications	Kitchen Counter Top, Dining Table, Office Table, Shelves
Features	Slip Resistance, Stain Resistance, Acid Resistance, Easy to Clean

Characteristics	Standard as per ISO-13006/EN14411 Group	Values	Test Method
Regulatory Properties
Deviation in Length & Width	+0.5%	+0.2%	ISO 10545-2
Deviation in Thickness	±5%	±5%	ISO 10545-2
Straightness of Sides	+0.5%	+0.2%	ISO 10545-2
Rectangularity	+0.5%	+0.2%	ISO 10545-2
Surface Flatness	+0.5%	+0.3%	ISO 10545-2
Color Difference	ΔE≤1.00	ΔE≤0.30	ISO 10545-16
Glossiness	As per Mfg.	>90%	Gloss Meter 60
Structural Properties
Water Absorption	≤0.5%	≤0.06%	ISO 10545-3
Apparent Density	As per Mfg.	>2.20 g/cc	ISO 10545-3
Massive Mechanical Properties
Modulus of Rupture	Min. 35N/mm²	Min. 40N/mm²	ISO 10545-4
Breaking Strength	Min. 1300 N	Min. 7200 N	ISO 10545-4
Impact Resistance	As per Mfg.	Min. 0.55	ISO 10545-4
Surface Mechanical Properties
Surface Abrasion Resistance	As per Mfg.	Min. class 3	ISO 10545-7
Moh’s Hardness	As per Mfg.	Min. class 4	BS EN 15771
Thermo Hygrometric Properties
Frost Resistance	As per Mfg.	Frost Proof	ISO 10545-12
Thermal Shock Resistance	Min. 10 Cycle	Min. 10 Cycle	ISO 10545-9
Moisture Expansion	Max. 0.6mm/m	Max. 0.02mm/m	ISO 10545-10
Thermal Expansion	Max. 9.0 x 10⁻⁶	Max. 6.0 x 10⁻⁶	ISO 10545-8
Chemical Properties
Chemical Resistance	As per Mfg.	No Damage	ISO 10545-13
Stain Resistance	Resistant	Resistant	ISO 10545-14
Safety Properties
Slip Resistance	As per Mfg.	N, A	DIN 51130
Fire Resistance	As per Mfg.	Fire Proof	N, A
